180PCS Nylon Waterproof Electrical Cable Wire Splice Heat Shrink Wire Connector Marine Automotive Heat-Resistant Terminals Set
Detail produk:
| Tempat asal: | Cina |
| Nama merek: | QW |
| Nomor model: | kuning mawar merah biru |
Syarat-syarat pembayaran & pengiriman:
| Kuantitas min Order: | 2 |
|---|
|
Informasi Detail |
|||
| Jenis: | Sambatan | Warna: | kuning mawar merah biru |
|---|---|---|---|
| Bahan: | Nilon+kaleng | Sertifikat: | ISO9001 SGS CE CQC ROHS |
| Nama Produk: | Solder Seal Wire Connectors | Rentang kawat: | 10-12/ 14-16/ 18-22 AWG |
| Kemasan: | 180/200/210/220/240/250/270/480pcs/kotak | Moq: | 1box |
| Barang: | Tubing heatshrink | Aplikasi: | Koneksi kawat |
| Penggunaan: | Menghubungkan kabel | ||
| Menyoroti: | nylon waterproof wire connectors,heat shrink electrical terminals,marine automotive cable splice set |
||
Deskripsi Produk
| Property | Specification Requirement | Test Method | Typical Value |
| Tensile strength(Room temp.) | Min.10.4Mpa | UL224 | 17.2Mpa |
| Elongation at break(Room temp.) | Min.200% | UL224 | 280% |
| Tensile strength after aging(158℃ 168hrs) | Min.7.3Mpa | UL224 | 11.5Mpa |
| Elongation after aging(158℃ 168hrs) | Min.100% | UL224 | 200% |
| Voltage withstand(Uh-aged) | Withstand 2.5kv for 1 minute and breakdown | UL224 | pass |
| Voltage withstand(Aged) | Withstand at least half of un-aged breakdown voltage for 1 minute and breakdown |
UL224 | pass |
| Copper corrosion(158℃ 168hrs) | No corrosion of bare copper | UL224 | No sign of deg. |
| Copper stabiity(158℃ 168hrs) | No sign of degradation (min.elongation 100%) | UL224 | pass |
| Cold blend(-30℃ 1hrs) | No crack | UL224 | pass |
| Maximum secant modulus(2%) | 173Mpa | UL224 | pass |
| Volume resistivity | Min.1014Ω.m | UL224 | pass |
| Heat shock(250℃ 4hrs) | No crack | ASTM D2671 | pass |
| Dielectric strength | >15.8kv/mm | ASTM D2671 | >25kv/mm |
Company Information
Certifications
CNBX Insulated Heat Shrink Waterproof Electrical Terminal Solder Seal Wire Connector Crimping Set.Hampool 270pcs Marine wiring harness heat resistant Waterproof Heat Shrink Duraseal electric Wire Connectors Terminals Kit.480pc Insulated Waterproof Auto Terminal Set Heat Shrink Wire Connector kit
Ingin Tahu lebih detail tentang produk ini
